Concrete Overlays

The Best Choice for Durable Pavement Overlays


Overlays | Installation Process | Design Factors | Success Story | Ultra-Thin Overlays




concrete overlay

A deteriorated asphalt parking lot, full of potholes and puddles, is both an eyesore and a safety hazard to everyone who uses it. Owners can transform a rutted asphalt surface into an attractive, functional parking area by covering it with a concrete overlay, or whitetopping. Standard overlays are 4-6 inches thick, but they can be as thin as 2 inches (for low-volume roads) or as thick as 17-20 inches (for airport runways). One of the advantages of overlays are their simplicity: surface preparation is minimal, and existing concrete paving equipment can be used for placement.

A properly-designed concrete overlay will provide many years of low-maintenance service. Most projects have an expected life cycle of at least 20 years, while some have lasted for as long as 30-40 years. Although concrete has a higher initial cost than asphalt, it lasts much longer and requires less maintenance, resulting in a significantly lower life cycle cost. An alternative to conventional concrete overlays are ultra-thin overlays, a durable, fast, and competitively-priced overlay technology which has generated much interest in recent years.


concrete overlaysAutoCAD Files that Complement the
Guide to Concrete Overlays of Asphalt Parking Lots

The RMC Research & Education Foundation and the National Concrete Pavement Technology Center (CP Tech Center) released the Guide to Concrete Overlays of Asphalt Parking Lots publication last fall to rave reviews.


In an effort to make the Guide even more useful, below we provide AutoCAD files for many of the Guide's Figures (please note, you need to appropriate software to be able to open & view).



Figure 25a

Figure 25b

Figure 26a

Figure 26b

Figure 26c

Figure 27a

Figure 27b

Figure 27c

Figure 27d

Figure 27e

Figure 27f

Figure 28a

Figure 28b

Figure 29a

Figure 29b

Figure 29c

Figure 30a

Figure 30b

Figure 30c

Figure 30d

Figure 30e

Figure 31a

Figure 31b

Figure 31c

Figure 31d

Figure 31e

Figure 31f

Figure 31g

Figure 32a

Figure 32b

Figure 32c

Figure 33a

Figure 33b

Figure 33c

Figure 33d

Figure 33e

Figure 33f

Figure 34a

Figure 34b

Figure 34c

Figure 34d

Figure 34e

Figure 35

Figure 36



Design of Concrete Overlays for Asphalt Parking Lots
A Publication by NRMCA and PCA

Also check out the Guide to Concrete Overlay Solutions (PDF),
a 32-page report by the National Concrete Pavement Technology Center.
